Polyurethane Spray Foaming Machine

Feature

1- Pneumatic motor

The pneumatic motor adopt the lastest direction-change for double direction work, has more stable

performance compare to electric one, suitable for complicated sitework condition.

2- High precision proportion pump

The proportion pump is made from stainless steel, to reduce the abrasion to seals, lengthen the

machine life. Equipped with oil tank for DOP solvent to clean the scrap material.

3- Main machine heating system

The main machine adopt separate aluminum heater, equipped with powerful heating bar for better

heating capacity, suitable for low temperatuer work in winter. The temperature control system with

number display, with measuring and overload protection system to control temperature exactly.


Power	4.0kw
Voltage	380v50HZ
Air Pressure	0.5Mpa—0.8 Mpa
Labor	1people
Max.Efficiency	160pcs/8h
Weight	300kg
Size（mm）(L*W*H)	850*750*1200

    This machine is a kind of pressure-driven high-pressure foaming system. When the water tank foam used in foam liquid, using the most advanced technology SBP, effective flow of raw materials to ensure the stability of the pressure. So that more should be two-component mixture of raw materials, but also uses high-power, high gas pressure, solve the problem of small foam machine guns blocked.
